Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Torque (Ft Lbs):
    128
  • Torque (Nm):
    173.5
  • Valves:
    8
  • Valve Configuration:
    SOHC
  • Bore (in):
    4.25
  • Stroke (in):
    3.8
  • Displacement (cc):
    1769
  • Compression Ratio:
    11.0:1
  • Torque RPM:
    3800
  • Fuel Injector Size (mm):
    52
  • Horsepower (bhp):
    122
• TRANSMISSION

  add remove
  • Number Of Speeds:
    6
  • Gear Ratio (1):
    10.17
  • Gear Ratio (2):
    6.93
  • Gear Ratio (3):
    5.15
  • Gear Ratio (4):
    4.11
  • Gear Ratio (5):
    3.51
  • Gear Ratio (6):
    3.02
  • Final Drive Ratio:
    2.38
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    98.5
  • Width (in):
    39
  • Height (in):
    56.2
  • Wheelbase (in):
    65.7
  • Dry Weight (lbs):
    796
  • Wet Weight (lbs):
    831
  • Fuel Capacity (gal):
    6
  • Engine Displacement to Weight (cc):
    2.22
  • Ground Clearance (in):
    5.4
• WHEELS & TIRES

  add remove
  • Front Tire (Full Spec):
    Metzeler Cruisetec: 130/60 B19 66H
  • Rear Tire (Full Spec):
    Metzeler Cruisetec: 180/60R16 80H
