Specifications

• PRICING

  add remove
  • Price:
    Standard
  • MSRP:
    13190
  • MSRP + Destination:
    13190
  • Currency:
    US Dollars
  • Warranty (Months):
    24
  • Warranty (Condition):
    Limited
• ENGINE

  add remove
  • Engine:
    Standard
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    76
  • Horsepower (kW):
    56
  • Horsepower RPM:
    7750
  • Torque (Ft Lbs):
    60.5
  • Torque (Nm):
    82
  • Torque RPM:
    5000
  • Cooling:
    Air
  • Valves:
    4
  • Valves Per Cylinder:
    2
  • Valve Configuration:
    OHV
  • Bore (mm):
    84
  • Bore (in):
    3.31
  • Stroke (mm):
    77
  • Stroke (in):
    3.03
  • Displacement (cc):
    853
  • Displacement (ci):
    52
  • Compression Ratio:
    10.5:1
  • Starter:
    Electric
  • Fuel Type:
    Gas
  • Fuel Requirements:
    Regular
  • Carburetion:
    Standard
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Parental Controls:
    Not Available
  • Turbocharged:
    No
  • Supercharged:
    No
  • Fuel Injector Size (mm):
    52
  • Speed Governor:
    No
  • Other Engine:
    Not Available
  • US Miles Per Gallon (Combined):
    48
  • CAN Liters Per Kilometer (Combined):
    4.9
• ELECTRIC ENGINE

  add remove
  • Electric Engine:
    Not Available
  • Battery:
    Not Available
  • Battery Charging System:
    Not Available
• TRANSMISSION

  add remove
  • Transmission:
    Standard
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    No
  • Heel Toe Shifter:
    Not Available
  • Adjustable Throttle:
    Not Available
  • Overdrive:
    Yes
  • Primary Drive (Engine / Transmission):
    Gear
  • Gear Ratio (1):
    2.44
  • Gear Ratio (2):
    1.78
  • Gear Ratio (3):
    1.33
  • Gear Ratio (4):
    1.08
  • Gear Ratio (5):
    0.96
  • Gear Ratio (6):
    0.89
  • Other Transmission:
    Not Available
• TECHNICAL SPECIFICATIONS

  add remove
  • Dimensions:
    Standard
  • Length (in):
    88.2
  • Length (mm):
    2240
  • Width (in):
    37.4
  • Width (mm):
    950
  • Wheelbase (in):
    60.2
  • Wheelbase (mm):
    1530
  • Ground Clearance (in):
    8.2
  • Ground Clearance (mm):
    208.3
  • Weight:
    Standard
  • Dry Weight (lbs):
    461
  • Dry Weight (kg):
    209
  • Capacities:
    Standard
  • Fuel Capacity (gal):
    6.1
  • Fuel Capacity (l):
    23
  • Fuel Capacity Reserve (gal):
    1.3
  • Fuel Capacity Reserve (l):
    5
  • Performance:
    Standard
  • Engine Displacement to Weight (cc):
    1.85
  • Wet Weight (lbs):
    507
  • Wet Weight (kg):
    230
• EXTERIOR

  add remove
  • Construction:
    Standard
  • Frame:
    Steel
  • Floor Boards:
    Not Available
  • Foot Pegs:
    Standard
  • Foot Peg Location:
    Driver and Passenger
  • Hand Grips:
    Standard
  • Handlebars:
    Standard
  • Handlebar Pads:
    Not Available
  • Exterior Guards:
    Standard
  • Belt Guard:
    No
  • Brush Guard:
    No
  • Chain Guard:
    No
  • Fork Guards:
    No
  • Hand Guards:
    Yes
  • Light Guard:
    No
  • Saddle Bag Guard:
    No
  • Exterior Covers:
    Standard
  • Front Fender:
    Standard
  • Front Fender Trim:
    Not Available
  • Front Fender Rail:
    Not Available
  • Rear Fender:
    Standard
  • Rear Fender Trim:
    Not Available
  • Rear Fender Rail:
    Not Available
  • Top Crown:
    Standard
  • Tank Divider:
    Not Available
  • Stand:
    Standard
  • Stand Type:
    Kick
  • Upper Fairing:
    Not Available
  • Lower Fairing:
    Not Available
  • Spoiler:
    Not Available
  • Skid Plate:
    Not Available
  • Wind Deflector:
    Not Available
  • License Plate:
    Standard
  • Engine Case Guard:
    Yes
  • Heel Guards:
    No
  • Side Cover:
    Yes
  • Other Exterior:
    Not Available
  • Exhaust Guard:
    No
  • Body Material:
    Plastic
  • Radiator Cover:
    No
  • Pocket:
    No
• STEERING

  add remove
  • Steering:
    Standard
  • Steering Control:
    Handlebar
  • Other Steering:
    Not Available
• SUSPENSION

  add remove
  • Front Suspension:
    Standard
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.6
  • Front Suspension Size (mm):
    41
  • Front Travel (in):
    6.7
  • Front Travel (mm):
    170
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension:
    Standard
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    6.7
  • Rear Travel (mm):
    170
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Air Adjustable:
    No
  • Rear Suspension Material:
    Aluminum
  • Other Suspension:
    Not Available
• WHEELS & TIRES

  add remove
  • Wheels:
    Standard
  • Wheels Composition:
    Aluminum
  • Front Wheel Width (in):
    2.5
  • Rear Wheel Width (in):
    4.3
  • Tires:
    Standard
  • Front Tire Width:
    110
  • Front Tire Aspect Ratio:
    80
  • Front Wheel Diameter:
    19
  • Rear Tire Width:
    150
  • Rear Tire Aspect Ratio:
    70
  • Rear Wheel Diameter:
    17
  • Front Tire (Full Spec):
    Michelin® Anakee Adventure: 110/80 - R19
  • Rear Tire (Full Spec):
    Michelin® Anakee Adventure: 150/70 - R17
  • Spare Tire:
    Not Available
  • Tire Brand:
    Michelin®
  • Other Wheels & Tires:
    Not Available
• BRAKES

  add remove
  • Brakes:
    Standard
  • Brake Brand Name:
    Brembo®
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.6
  • Front Brake Diameter (mm):
    320
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.2
  • Rear Brake Diameter (mm):
    260
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Standard
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
  • Other Brakes:
    Not Available
• SEATS

  add remove
  • Seat:
    Standard
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Vinyl
  • Seat Specifications:
    Standard
  • Seat Height (in):
    32.7
  • Seat Height (mm):
    830
  • Number Of Seats:
    2
  • Detachable Passenger Seat:
    Not Available
  • Seat Backrest:
    Not Available
  • Seat Tail Cover:
    Not Available
  • Seat Rail:
    Not Available
  • Grab Rail or Strap:
    Standard
  • Heated Seat:
    Not Available
  • Sidecar:
    Not Available
  • Backrest Logo Plate:
    No
  • Lumbar Adjustment:
    No
  • Detachable:
    No
  • Other Seat:
    Not Available
• GLASS

  add remove
  • Folding:
    Yes
  • Rearview Mirrors:
    Standard
  • Windshield:
    Standard
  • Sidecar Windshield:
    Not Available
  • Windshield Wipers:
    Not Available
  • Tinted:
    Yes
  • Height:
    High
  • Height Adjustable:
    No
  • Windshield Lowers:
    No
  • Other Glass:
    Not Available
• INSTRUMENTATION

  add remove
  • Digital Instrumentation:
    Standard
  • Clock:
    Standard
  • Speedometer:
    Standard
  • Tachometer:
    Standard
  • Trip Odometer:
    Standard
  • Trip Computer:
    Standard
  • Compass:
    Standard
  • Navigation System:
    Standard
  • GPS:
    Standard
  • Lap Timer:
    Not Available
  • Fuel Level Warning:
    Standard
  • Fuel Level Warning Type:
    Light
  • Oil Pressure Gauge:
    Not Available
  • Temperature Warning:
    Standard
  • Temperature Warning Type:
    Light
  • Shift Light:
    Not Available
  • Multi-Lingual Instrumentation:
    Not Available
  • Battery Status Gauge:
    Not Available
  • Energy Consumption Gauge:
    Not Available
  • Other Instrumentation:
    Not Available
• STORAGE

  add remove
  • Hard Side Cases:
    Standard
  • Side Storage Mount:
    Standard
  • Fork Bag:
    Not Available
  • Tail Bag:
    Not Available
  • Tank Bag:
    Not Available
  • Leather Storage:
    Not Available
  • Underseat Storage:
    Not Available
  • Lockable Storage:
    Optional
  • Front Rack:
    Not Available
  • Front Rack Storage:
    Not Available
  • Rear Rack:
    Standard
  • Rear Rack Storage:
    Standard
  • Side Rack:
    Not Available
  • Side Rack Storage:
    Not Available
  • Bag Liners:
    Optional
  • Cupholder:
    Not Available
  • Storage Cover:
    Not Available
  • Sidecar Storage Cover:
    Not Available
  • Map Holder:
    Not Available
  • Helmet Storage:
    Standard
  • Sidecar Front Rack:
    Not Available
  • Sidecar Rear Rack:
    Not Available
  • Sidecar Fender Rack:
    Not Available
  • Sidecar Trunk:
    Not Available
  • Side Case Material:
    Aluminum
  • Number Of Side Cases:
    2
  • Hard Side Case Capacity (gal):
    16.3
  • Hard Side Case Capacity (l):
    72
  • Glove Box / Dash Storage:
    Not Available
  • Camouflage Trim:
    No
  • Other Storage:
    Not Available
  • Rear Rack Storage Material:
    Aluminum
  • Rear Rack Storage Trim:
    Plain
• LIGHTS

  add remove
  • Headlight(s):
    Standard
  • Type:
    LED
  • Halogen Headlight(s):
    Standard
  • Adjustable Headlights:
    Not Available
  • Fog Lights:
    Optional
  • Headlight Mounts:
    Standard
  • Headlight Mounting Bar:
    Not Available
  • Headlight Visor:
    Not Available
  • Turn Signal Visor:
    Not Available
  • Passing Lamps:
    Not Available
  • Passing Lamp Visors:
    Not Available
  • Other Lights:
    Not Available
• CONVENIENCE

  add remove
  • Engine Immobilizer:
    Standard
  • Heated Hand Grips:
    Standard
  • Keyless Ignition:
    Not Available
  • Power Outlet:
    Standard
  • Cruise Control:
    Standard
  • Adjustable Handlebars:
    Not Available
  • Adjustable Levers:
    Not Available
  • First Aid Kit:
    Not Available
  • Adjustable:
    Yes
  • Heated Hand Grip Location:
    Driver
  • Handlebar Lock:
    Standard
  • Other Convenience:
    Not Available
• AUDIO & COMMUNICATION

  add remove
  • Radio:
    Not Available
  • Speakers:
    Not Available
  • Cassette Player:
    Not Available
  • CD Player:
    Not Available
  • CB Radio:
    Not Available
  • Intercom:
    Not Available
  • Headset:
    Not Available
  • Satellite:
    No
  • Other Audio & Communication:
    Not Available
  • Wireless / Connectivity:
    Standard
  • Bluetooth® Audio:
    No
  • Mobile App Instrumentation:
    Yes
• MOUNTS

  add remove
  • Side Case Mount:
    Standard
  • Tool Bag Mount:
    Not Available
  • Windshield Mounts:
    Standard
• PAINT & FINISH

  add remove
  • Paint:
    Standard
  • Secondary Color:
    Not Available
  • Metallic:
    No
  • Decal Kit:
    Standard
  • Other Paint & Finish:
    Not Available
