Specifications

• Dimensions

  add remove
  • Length:
    92.1 in
  • Seat height, unladen:
    28.0 in
  • Ground clearance:
    4.7 in
  • Rake (steering head):
    28
  • Trail:
    5.2 in
  • Wheelbase:
    63.6 in
  • Tires, front specifications:
    150/80-16,71H,BW
  • Tires, rear specifications:
    180/70B16,77H,BW
  • Fuel Capacity:
    3.5 gal
  • Oil capacity:
    5 qt.
  • Weight, as shipped:
    653 lbs
  • Weight, in running order:
    675 lb
• Engine

  add remove
  • Engine:
    Milwaukee-Eight® 114
  • Bore:
    4.0 in
  • Stroke:
    4.5 in
  • Displacement:
    113.99 in³
  • Compression ratio:
    10.5:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-into-2 shorty dual; catalyst in muffler
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    118.0 ft-lb
  • Engine torque (RPM):
    3500
  • Lean angle, right (deg.):
    31
  • Lean angle, left (deg.):
    32
  • Fuel economy testing method:
    EU 134/2014
  • Fuel economy:
    47 mpg (5 l/100km)
  • CO₂ emissions testing method:
    EU 134/2014
  • CO₂ emissions :
    128 g/km CO₂
• Powertrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.311
  • Gear ratios (overall) 2nd:
    6.454
  • Gear ratios (overall) 3rd:
    4.793
  • Gear ratios (overall) 4th:
    3.882
  • Gear ratios (overall) 5th:
    3.307
  • Gear Ratios (overall) 6th:
    2.79
• Chassis

  add remove
  • Wheels, front type:
    Denim black, Structure cast aluminum with laser etched graphics
  • Wheels, rear type:
    Denim black, Structure cast aluminum with laser etched graphics
  • Brakes, caliper type:
    4-piston fixed front and 2-piston floating rear
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    High beam, turn signals, neutral, low oil pressure, engine diagnostics, ABS (if equipped), security, low battery voltage, low fuel
  • Gauges:
    4-inch analog tachometer with digital speedometer, gear, odometer, fuel level, clock, trip and range indication
