Specifications

• Dimensions

  add remove
  • Length:
    85.2 in
  • Dry Weight:
    545 lbs
  • Ground clearance:
    4.3 in
  • Rake (steering head):
    30.2
  • Trail:
    5.3 in
  • Wheelbase:
    1,495.0 in
  • Tires, front specifications:
    130/90B16 73H
  • Tires, rear specifications:
    150/80B16 77H
  • Fuel Capacity:
    2.1 gal
  • Oil capacity:
    2.8 qt.
  • Weight, as shipped:
    545 lbs
  • Weight, in running order:
    556 lb
  • Luggage capacity – volume:
    N/A
• Engine

  add remove
  • Engine:
    Air-cooled, Evolution®
  • Bore:
    3.5 in
  • Stroke:
    3.8 in
  • Displacement:
    1,201.98 in³
  • Compression ratio:
    10:01
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    Black, staggered, shorty exhaust with dual mufflers
• Performance

  add remove
  • Engine torque testing method:
    J1349
  • Engine torque:
    70.8 ft-lb
  • Horsepower:
    66 HP / x49 Kw @ 6000 rpm
  • Lean angle, right (deg.):
    27.1
  • Lean angle, left (deg.):
    27.1
  • Fuel economy testing method:
    Estimated City/Hwy
  • Fuel economy:
    0.00 mpg
• Powertrain

  add remove
  • Primary drive:
    Chain, 38/57 ratio
  • Gear ratios (overall) 1st:
    9.315
  • Gear ratios (overall) 2nd:
    6.653
  • Gear ratios (overall) 3rd:
    4.948
  • Gear ratios (overall) 4th:
    4.102
  • Gear ratios (overall) 5th:
    3.517
  • Gear Ratios (overall) 6th:
    N/A
• Chassis

  add remove
  • Wheels, optional style type:
    N/A
  • Wheels, front type:
    Black, Split 9-Spoke Cast Aluminum w/ Machined Highlights
  • Wheels, rear type:
    Black, Split 9-Spoke Cast Aluminum w/ Machined Highlights
  • Brakes, caliper type:
    Dual-piston front, Dual-piston rear
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (if equipped), ABS (if equipped)
  • Gauges:
    Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights
