Specifications

• ENGINE

  add remove
  • Engine Type:
    Horizontal In-line
  • Bore And Stroke:
    67mm x 42.5mm
  • Induction:
    Dual Stage Fuel Injection (DSFI) with 40mm throttle bodies, Denso 12-hole injectors
  • Ignition:
    -controlled transistorized with 3-D mapping
  • Compression Ratio:
    12.2:1
  • Valve Train:
    DOHC; four valves per cylinder
  • Final Drive:
    #525 O-ring chain
• Chassis/ Suspension/ Brake

  add remove
  • Front Suspension:
    41mm inverted Big Piston Fork with spring preload, rebound compressiondamping adjustability; 4.3 inches travel
  • Rear Suspension:
    Unit Pro-Link® HMAS™ single shock with spring preload, rebound compressiondamping adjustability; 5.1 inches travel
  • Front Brake:
    Dual radial-mounted four-piston calipers with full-floating 310mm discs
  • Rear Brake:
    Single-caliper 220mm disc
  • Front Tire:
    120/70ZR-17 radial
  • Rear Tire:
    180/55ZR-17 radial
• Dimensions

  add remove
  • Rake:
    23.5° (Caster Angle)
  • Trail:
    97.7mm (3.9 inches)
  • Wheelbase:
    53.9 inches
  • Seat Height:
    32.3 inches
  • Curb Weight:
    410 pounds (Includes all standard equipment, required fluids and a full tank offuel—ready to ride)
  • Fuel Capacity:
    4.8 gallons
  • Miles Per Gallon:
    44 MPG*
• Other

  add remove
  • Emissions:
    Meets current EPA standards. California version meets current CARB standards andmay differ slightly due to emissions equipment.
• Factory Warranty Information

  add remove
  • Warranty:
    Transferable, unlimited-mileage limited warranty; extended coverage available witha Honda Protection Plan.
